It can be used for liquid level detection in complex electromagnetic environment, and is mainly used in DC transmission converter valve products.
Technical indicators | |
Operating wavelength | 850nm±10nm |
Insertion loss(no level detected) | ≤3dB |
Insertion loss (level detected) | ≥30dB |
Redundant channel consistency | The height difference between the two channels of the same module detecting liquid level ≤ 0.5mm |
Operating temperature | -10℃~+60℃ |
Storage temperature | -40℃~+70℃ |
Fiber type | Multimode (200/230μm,62.5/125μm) |
Optical interface | ST/UPC |
